INFICON AST-ID Automotive Refrigerant Identifier

INFICON AST-ID Automotive Refrigerant Identifier

JAST-ID

AST-ID is designed to verify that the refrigerant in a vehicle or cylinder meets the purity standard necessary for use or reuse. AST-ID also reveals the presence of contaminants like hydrocarbons and oxygen, both of which can negatively impact the performance of an AC system. Protect your refrigerant supply from potential contamination and optimize AC performance with the accurate, easy-to-use AST-ID.

Specifications:

• Includes: AST-ID, Sample hose with oil restrictor, R134a vehicle low side quick connect, R1234yf vehicle low side quick connect, R134a cylinder adapter, R1234yf cylinder adapter, AC wall charger, Calibration certificate & Carrying case
• Compatible refrigerants: R134a and R1234yf
• Data output format: SAE or VDA (selectable)
• Sample type: Vapor (less than 5 g per test)
• Oxygen sensor life: 5 years typical
• Infrared sensor life: 5 years typical
• Power source: Lithium ion battery (rechargeable)
• Battery life: ~8 hours
• Weight: 2.7 lbs (1.2 kg)
• Certifications: CE, UKCA, SAE J2912, SAE 2927 (AST-ID Integrated) & UL 61010
• Sample tube length: 67 in. (1.7 m)
